Vehicle Type | Scooter |
Fuel | Electric |
Engine Starting | Electric |
Load Carrying Capacity | 150 kg |
Climbing Degree | 10° |
Top Speed | 25 kmph |
Motor Details |
---|
Motor Type: BLDC Brand KETRON Power: 250W IP Level: IP57 |
Range |
---|
120-160 Km |
Charging Time |
---|
4-5 hrs |
Display |
---|
Digital Display |
Electricals | |
---|---|
Battery | Type: Lithium Portable Capacity : 26 AH + 26 AH Voltage: 60V Battery Size: 200 x 159 x 280 mm |
Charger | Output Volt: 69.5 V Output Current: 3A Input Volt: 176V 264 Socket: Indian-Three Pin-Round |
Controller | Brand: KETRON 12 tubes Input Volt/ Watt: 60V250W Maximum Current: 32A |
Warranty for Battery | 3 Years |
Head Lamp | LED |
Tail Lamp | LED |
Brakes | |
---|---|
Front Brake | Disc Brake |
Rear Brake | Drum Brake |
Chassis and Suspension | |
---|---|
Front Suspension | 31x365 Hydraulic |
Rear Suspension | 30x280 Hydraulic |
Tyres | |
---|---|
Wheels / Rim | Alloy |
Front Tyre | 90/100-10 |
Rear Tyre | 90/100-10 |
Dimensions | |
---|---|
Length | 1785 mm |
Width | 750 mm |
Height | 1080 mm |
Weight | 87 kg |
Ground Clearance | 140 mm |
Vehicle Warranty |
---|
Charger: 1 Year Controller: 3 Years Motor: 3 Years |
